Wolf 1.6 Tons Zl16 Agriculture Farm Hydraulic Pilot Joystick Control From End Shovel Cheaper Price Wheel Loader for Sale
Package Size 5200.00cm * 1750.00cm * 2700.00cm Package Gross Weight 3300.000kg Standard configuration: Changchai 490 eng
Send your inquiryDESCRIPTION
Basic Info.
| Model NO. | WL922 |
| Condition | New |
| Rated Load | 2ton |
| Transmission | Hydraulic |
| Load and Unload Mode | Front Discharge |
| Walking Mode | Wheeled |
| Type | Small Loader |
| Operating Weight | 3300kg |
| Tyre | 20.5-16 |
| Max.Dump Height | 2850/3200mm |
| Maximum Breakout Force | 51kn |
| Minimum Turning Radius | 3600mm |
| Optional Tire | 31X15.5-15 |
| Optional Engine | Xi Chai/Xin Chai |
| Overall Size | 5200X1750X2700 |
| Rated Bucket Capacity | 0.9-.1.1 |
| Wheel Thread | 1400mm |
| Wheel Base | 1975mm |
| Rated Power | 39kw |
| Rated Speed | 2400rpm |
| Engine Model | Changchai 490 |
| Transport Package | 1 Set in 20gp, 3 Sets in 40hq |
| Specification | 5200x1750x2700 |
| Trademark | Wolf |
| Origin | Shandong, China |
| HS Code | 84295100 |
| Production Capacity | 3000sets/Year |
Packaging & Delivery
Package Size 5200.00cm * 1750.00cm * 2700.00cm Package Gross Weight 3300.000kgProduct Description
Standard configuration: Changchai 490 engine,4WD, 20.5/70-16 tires, mechanical joystick, standard bucket, Camel Battery,, luxury cabin ,bucket can be level automatic, back sound, hand brake, extinguisher, window hammer, Free parts, tool box.| joystick | Display |
| Hydraulic System | |
| Frame | Standard Bucket |
Optional:
Xinchai Euro 3 engine/Yanmar engine, Quick Hitch, double heater, air conditioning, electric floating, extra Hydraulic Line, electronic joystick, different attachments etc.
More Pictures:
| Performance | Rated loading | 1600kg |
| Overall weight | 3300kg | |
| Rated bucket capacity | 0.9m3 | |
| Maximum tractive force | ≥34KN | |
| Maximum breakout force | ≥51KN | |
| Maximum grade ability | 30° | |
| Maximum dump height | 2200mm | |
| Maximum dump reach | 800mm | |
| Overall dimension (L×W×H) | 5200x1750x2700mm | |
| Minimum turning radius | 3600mm | |
| Engine | Standard model | Changchai490 |
| Optional model | Xinchai490 E3Xinchai498 E3 | |
| Type | Vertical, in-line, water cooled, 4-stroke diesel engine | |
| No. of cylinder-bore/stroke | 4-100×125mm | |
| Rated power | 39kw-2200r/min | |
| Maximum torque | 250N.m | |
| Min fuel-consume ratio | ≤243g/kw.h | |
| Transmission system | Torque converter | YJ1-26501 |
| Gearbox mode | Counter shaft power-shift | |
| Gear shift | 2 forward shift 2 reverse shift | |
| Maximum speed | 20km/h | |
| Tyre | Type specification | 20.5/70-16 |
| Front tyre pressure | 0.22Mpa | |
| Rear tyre pressure | 0.22Mpa |
There are different colors for you to choose, or you can customize your own color.
With more than 10 years' exporting experience. All of the machine are CE approved.
Packing: 1 set in 1*20GP (cabin removed), 3 sets in 1*40HQ (cabin removed)
Warranty:We have 12 months warranty, within 12 months, if any parts broken because of quality problem without human causes, send us related pictures/videos, we will send good parts to you for free, within 7 working days, ensure the problem could be solved as soon as possible. After the warranty period, we will provide zero-profit spare parts support. our professional after sales team is ready to help at any time when there is any problem,and supply of replacement parts could be guaranteed no matter how many years your loader has been used. Choosing Wolf,you will have one year warrant and a life-time service!
